4D Systems 4DGL-Platform Intelligent OLED Display Modules

4D Systems Intelligent OLED Graphic Display Modules are compact and cost-effective display modules using the latest state-of-the-art Passive Matrix OLED (PMOLED) technology with an embedded GOLDELOX graphics processor that delivers 'stand-alone' functionality to any project. Powerful graphics, text, image, animation, and countless more features are built inside the GOLDELOX chip.

The display modules are designed to work out-of-the-box and are programmed with 4D Graphics Language using 4D Workshop4 IDE (editor, compiler, and downloader). 4DGL is a graphics-oriented language allowing the developer to write applications in a high-level language with syntax similar to popular languages such as BASIC, C, and Pascal. The modules offer modest but comprehensive I/O features that can interface to serial, analog, digital, buttons, joystick, sound generation, and Dallas 1-wire devices. All these features are combined to offer one of the most flexible embedded graphics solutions available.

These modules can be programmed using 3 different environments in the Workshop4 IDE. Designer, ViSi, and Serial. Please refer to the Workshop4 Product Page for more information and documentation on these environments.

Features

Low-cost OLED display graphics user interface solution
65K true to life colors, PMOLED screen
No backlighting with near 180º viewing angle
Easy 10 pin interface to any external device
Powered by the 4D-Labs GOLDELOX-GFX2 graphics processor highly optimized for 4DGL
2x GPIO ports supports:
- Digital I/O
- A/D converter with 8/10 bit resolution
- Complex sound generation
- Dedicated RTTTL tune engine
- Multi-switch joystick
- Dallas 1-Wire

10Kb of flash memory for user code storage and 510 bytes of RAM for user variables (255 x 16bit vars)
On-board micro-SD memory card adapter for storing of icons, images, animations, etc.; supports 64MB to 2GB micro-SD memory cards
Comprehensive set of built-in high-level 4DGL graphics functions and algorithms that can draw lines, circles, text, and much more
Display full-color images, animations, icons, and video clips
Supports all available Windows fonts and characters (imported as external fonts)
4.0V to 5.5V range operation (single supply)
RoHS compliant
